Thermal Relief Design: Balancing Heat Dissipation and Solderability

In Pcb Design, thermal relief is one of those topics that seems obscure until a board comes back from assembly with cold solder joints, lifted pads, or — paradoxically — traces that burned out under load. The thermal relief pattern surrounding a pad or via is the interface between the component, the copper, and the solder. Get it wrong in either direction, and problems follow.

This article explains what thermal relief actually does, how different configurations affect heat flow and solderability, and how to choose the right balance for your specific application.

What Is Thermal Relief, and Why Does It Exist?

When a solder pad is directly connected to a large copper plane — whether a power plane or a ground pour — the thermal mass of that plane acts as a heat sink. During Wave Soldering or reflow, the plane draws heat away from the joint faster than the soldering iron or solder wave can supply it. The result is an insufficiently heated joint that forms a cold, dull, unreliable solder connection.

Thermal relief solves this by interrupting the direct thermal path between the pad and the plane. Instead of a solid copper connection, the pad is linked to the plane by a series of narrow copper spokes. These spokes conduct enough heat to prevent the joint from running cold during assembly while limiting thermal short circuits that would otherwise cool the joint too quickly.

That last point surprises many designers: thermal relief is not just about keeping heat IN the pad during soldering — it is also about controlling how fast heat LEAVES the pad during solidification. A joint that overheats and then cools too rapidly after reflow can develop cracks and voids. Thermals that are too restrictive can leave the joint underheated entirely.

The Anatomy of a Thermal Relief

A typical thermal relief consists of four elements:

• The pad: The component landing area, usually circular or rectangular, sized for the component lead and solder fillet.
• The spoke or spokes: Narrow copper traces that connect the pad to the surrounding plane. Standard designs use 2, 4, or 8 spokes depending on the required thermal isolation.
• The thermal gap: The annular space between the pad and the plane that gives the relief its name. This air gap provides thermal isolation and is typically 0.3 mm to 0.5 mm wide.
• The plane: The large copper pour — usually power or ground — that provides the thermal path to the rest of the Pcb.

Different EDA tools generate thermal relief patterns with varying geometry. Understanding the parameters — spoke width, number of spokes, gap width — is the key to controlling the behavior.

Spoke Count and Width: How They Affect Performance

More Spokes = More Conductivity

Increasing the number of spokes increases the thermal and electrical conductivity between the pad and the plane. An 8-spoke thermal connects to the plane almost like a solid fillet — it provides minimal isolation and is used for through-hole vias where solderability is not a concern, only electrical connection.

A 2-spoke thermal provides strong isolation. It is the standard choice for pads connected to large planes that will be hand-soldered or run through a reflow oven, where the iron or reflow profile must heat the joint without fighting the plane's thermal sink.

4-spoke thermals are a middle ground — common in Wave Soldering applications where the solder wave itself provides sufficient thermal energy to overcome a moderately strong thermal connection.

Spoke Width: A Subtle but Significant Variable

Even with the same number of spokes, the width of each spoke dramatically changes thermal behavior. A 0.25 mm spoke carries far less heat than a 0.5 mm spoke of the same length and material. In high-current applications where the pad must also carry significant current to or from the plane, wider spokes provide the necessary current-carrying capacity. But wider spokes also conduct more heat, reducing the thermal relief's effectiveness.

The designer's job is to find the spoke geometry that satisfies two simultaneous constraints: adequate current capacity and adequate thermal isolation for the assembly process being used.

Thermal Relief vs. Thermal Pads: Are They the Same?

These terms are related but describe different things. Thermal relief refers to the spoke-based connection pattern between a pad and a plane. Thermal pad — more accurately called a thermal land — refers to a pad specifically designed for surface-mount power components such as MOSFETs, voltage regulators, or power diodes.

Thermal lands for SMD power components often omit thermals entirely, relying instead on multiple large vias to connect the pad to inner planes. The vias provide both electrical and thermal conduction to internal heat-spreading planes. For these pads, the concern is not solderability — the entire pad sits on top of the board and gets heated evenly from the reflow oven's top-side radiant heat — but thermal conduction from the component to the Pcb.

Understanding this distinction prevents a common design error: applying thermal relief geometry to a thermal land for a power MOSFET, which would actually reduce its thermal performance.

Assembly Method and Thermal Relief Selection

The choice of thermal relief configuration should be driven by how the board will be assembled:

Reflow Soldering

In Reflow Soldering, the board and all its components are heated uniformly in an oven. The primary heat source is radiant and convective, not conductive through the copper. For surface-mount pads connected to planes, thermal relief is generally not needed — the reflow profile heats the entire assembly above liquidus temperature, and the plane's heat sink effect is manageable with a well-tuned profile.

However, through-hole components on a reflow-assembled board — particularly those with large thermal mass leads — still benefit from thermal relief on their pads, especially if the board has thick copper planes.

Wave Soldering

Wave soldering presents the greatest thermal challenge for through-hole components. The solder wave contacts only the bottom of the board, and heat must conduct through the component lead, the pad, and into the plane before melting occurs. A solid pad-to-plane connection can chill the joint before the solder has a chance to wet properly.

For wave soldering, 4-spoke or even 2-spoke thermals with narrow gaps are the recommended starting point. Verify with your assembly partner — some wave solder pots run at temperatures above 260°C, which changes the required balance compared to a standard reflow profile.

Hand Soldering

Hand soldering with a temperature-controlled iron is the most thermally demanding process for individual joints. The operator's iron tip must deliver heat directly to the joint, and a plane that acts as a heat sink can make this nearly impossible — the iron tip temperature drops, the joint never reaches wetting temperature, and the operator either applies excessive heat (risking pad lift) or gives up and produces a cold joint.

For boards that will be hand-assembled or serviced, 2-spoke thermals with narrow gaps are strongly recommended. In extreme cases, particularly for grounding pads on large ground planes, consider routing a thin trace between the pad and plane rather than using spokes — the maximum possible thermal isolation for hand work.

Thermal Relief for High Current Pads

The thermal relief design challenge becomes most acute in power electronics, where a single pad may need to carry tens of amps from a plane to a component lead. Wide spokes are needed for current capacity, but wide spokes conduct heat away from the joint during soldering.

The solution in high-current designs is often a multi-layer approach:

• Use 4 wide spokes on the surface layer to carry the bulk of the current to the plane.
• Add multiple thermal vias directly under the pad to connect it to inner plane layers that distribute the current and heat.
• For the most demanding applications, use a copper coin or metal-core insert embedded in the board directly under the pad, which acts as a mechanical heat spreader and current bus.

This approach decouples the electrical current path from the thermal relief — the spokes handle current, while the vias handle thermal conduction to the internal planes. The thermal relief can then be designed for solderability alone, independent of the current requirements.

Thermal Relief for Annular Rings and Vias

Vias connected to planes present a simpler version of the thermal relief problem. The standard approach is to use a thermal spoke pattern — typically 4 spokes — around the via barrel, connecting it to the surrounding pour. This prevents the plane from acting as a heat sink during through-hole soldering while maintaining an adequate electrical connection.

For plated through-hole vias that do not need solderability — such as grounded vias in RF designs — thermal relief is unnecessary and a solid barrel connection is preferable, as it minimizes impedance and maximizes thermal conduction to the plane.

Common Thermal Relief Mistakes

• Using thermal relief on thermal pads for power SMD components. This reduces the component's ability to dump heat into the PCB, increasing junction temperature and reducing power handling capability.
• Over-isolating pads in high-current designs. Spokes that are too narrow or too few create resistive hot spots that degrade reliability over time due to electromigration and thermal cycling.
• Using thermal relief inside buried or blind vias. Thermal relief is a top-layer feature — it only affects the interface between the pad and the plane visible at that layer. Applying it to internal layers has no benefit and may complicate Manufacturing.
• Setting thermal gaps inconsistently. If different pads on the same net have different thermal relief configurations, the current distribution becomes uneven, potentially overloading certain spokes.
• Ignoring the manufacturer's default thermal settings. Most EDA tools ship with generic thermal relief parameters. These are rarely optimal — review and customize them for each design.

Calculating Thermal Relief Parameters

There is no universal formula for thermal relief design — it is ultimately an empirical balance. However, a few guidelines can anchor the starting point:

• For standard through-hole with 1 oz copper, 4 spokes of 0.2–0.3 mm width with a 0.3–0.4 mm gap provides good hand and wave solderability.
• For heavy copper (3 oz+), increase spoke width to at least 0.4–0.5 mm to carry the increased current while maintaining the same isolation level.
• For pads on planes larger than approximately 25 mm on a side, consider increasing gap width to 0.5 mm or wider — larger planes are more effective heat sinks.

When in doubt, ask your assembly partner for their recommended thermal relief settings for their specific equipment. This is free advice from people with extensive empirical data — use it.

Frequently Asked Questions

Can I use the same thermal relief for both reflow and wave soldering on the same board?
Yes, with care. A 4-spoke thermal with moderate gap width works well for both processes. If the board uses exclusively reflow, thermal relief can be reduced or omitted for SMD pads. If wave soldering is involved, stick with 4 spokes and confirm with your assembly vendor that the profile is appropriate for the gap width chosen.

My ground plane has many through-hole vias with thermal relief. Is this causing high impedance ground?
Thermally relieved vias do add resistance compared to a solid connection. For most digital designs at low frequencies, this resistance is negligible — fractions of a milliohm per via. For RF and high-frequency power designs, the cumulative resistance and inductance of thermal spokes can affect return current paths. In those cases, evaluate whether thermal relief is actually needed on those specific vias or whether a solid connection is acceptable for the assembly process.

Should I use thermal relief on micro-vias?
Micro-vias (laser-drilled, typically <0.15 mm diameter) are too small to benefit from thermal relief. They connect directly to planes or pads and rely on the plating thickness and the thermal mass of the surrounding structure for their solderability. Thermal relief on micro-vias is not standard practice.

How does thermal relief interact with solder mask?
Most EDA tools generate thermal relief patterns where the thermal gap is not covered by solder mask — the copper spokes and gap are exposed. This is intentional: solder mask over the spokes would insulate them and reduce thermal conduction. The thermal gap is explicitly kept clear to allow solder to flow freely around the pad during reflow and wave processes.

My EDA tool generates thermals automatically. Can I trust the defaults?
The defaults are reasonable starting points but not necessarily optimal for your specific design. Review the generated thermals against your copper weight, assembly process, and current requirements. Adjust spoke count, width, and gap width based on the guidelines above, and verify with your manufacturer before releasing the design for production.
